TR20 Thermal Imaging Gun Sight 384* 288 Ir Resolution And 35mm Focal Length

Place of Origin : China

Brand Name : OEM, ODM All Available

Certification : CE,FC,RoHS

MOQ : 10

Delivery Time : 3~7

Payment Terms : T/T. L/C, Western Union, Money Gram

Supply Ability : 30000PCS/Month

Model Number : TR20-25mm

Resolution : 384x288px

Frame rate : 50hz

Objective Iens : 25mm/f1.0

Magnification : 2.04 - 8.16 x

Digital zoom : 2x,4x

Size : 188.8*51*74.1mm

Weight : 560g

Contact Now

TR20 Thermal Imaging Gun Sight, 384* 288 Ir Resolution And 35mm Focal Length

Parameter:

TR20 25mmm
Resolution,Pixel 384×288
Refresh Rate 50Hz
Pixel Size, micron 12μm
Objective Lens 25mm/f1.0
Magnification 2.04 - 8.16 x
Digital zoom 2x,4x
Eyerelief 40mm
Field of View (HxV) 10.5 x 7.9
Dioptre adjustment, dpt ± 5
Reticle Type 8-Pattern optional, or “NO reticle”
Reticle Color 4 colors: White, Black, Red and blue
Image Palettes White Hot / Black Hot/ red hot /green hot/ Iron red / Sky
Display Resolution 1280x960
Laser locator 1mw red dot CAL
Detection distance Human(1.8×0.5)m 1000
Detection distance Vehicle(2.3×2.3)m 2500
Recognition distance Human(1.8×0.5)m 500
Recognition distance Vehicle(2.3×2.3)m 1000
Battery Type Li-ion 18650 Rechargeable Battery Replaceable
Battery Life (Operating) 5 hours
External power supply USB type c
Protection rate IP66
Operating Temperature -30℃ ... +60 ℃
Storage Temperature -50℃.. +70 ℃
Size (L × W × H),mm / inch 188.8mm*51mm*74.1mm
Weight (W/o battery),Kg/ oz 560g
Housing Materials Aluminum Alloy


Features:

1.Light weight,Compact size,Powerful functions
2.Rugged with high Shock Resistance
3.12um thermal imaging sensor, Ultra clear image quality
4.Mobile with Wifi connection for remote control
5. Expandable Laser Rangfinder (optional)

TR20 Thermal Imaging Gun Sight 384* 288 Ir Resolution And 35mm Focal LengthTR20 Thermal Imaging Gun Sight 384* 288 Ir Resolution And 35mm Focal LengthTR20 Thermal Imaging Gun Sight 384* 288 Ir Resolution And 35mm Focal LengthTR20 Thermal Imaging Gun Sight 384* 288 Ir Resolution And 35mm Focal Length
